ORACLE Lighting Vintage Series LED Headlight Bulbs
ORACLE Lighting Vintage Series LED Headlight Bulbs bring modern LED performance to classic and vintage vehicles while keeping a period-correct look. A warm 3000K-3500K color temperature mimics the glow of original sealed-beam and halogen bulbs, and a true drop-in design with no fans or bulky heat sinks fits older headlamp buckets where larger LED bulbs will not. The result is up to four times the visibility of stock halogen without the cold, blue aftermarket look.
Key Features
- Warm 3000K-3500K color temperature for a period-correct glow, no cold blue LED appearance
- True drop-in OEM fitment, same size and shape as factory halogen bulbs, no trimming or brackets
- Fanless design with no bulky heat sinks fits sealed-beam housings and older headlamp buckets
- Precision filament geometry replicates the halogen focal point for an OEM-style, no-glare beam
- Active thermal management via PWM current regulation protects the LED without a cooling fan
- 3,600 lumens per set, up to 4x the visibility of stock halogen bulbs
- 17W per bulb with over 100 lumens per watt efficacy
- 6-32V DC input range tolerant of the voltage swings common in older electrical systems
Fitment & Compatibility
Available in H4, H10, 9003, and 9004 fitments for classic muscle cars (Mustang, Camaro, Chevelle and similar), vintage trucks and SUVs (C10, F-100, Wagoneer and similar), and restomods or show vehicles. These bulbs are designed for classic reflector housings and sealed-beam buckets. Verify your bulb fitment before ordering.
Specifications
| Specification | Detail |
|---|---|
| ORACLE Part # | C5231-001 (H4), C5234-001 (H10), C5251-001 (9003), C5238-001 (9004) |
| Lumen Output | 3,600 lm per set |
| Power Draw | 17W per bulb |
| LED Efficacy | 100+ lumens per watt |
| Color Temperature | 3000K-3500K (warm white) |
| Input Voltage | 6-32V DC |
| Cooling | Fanless, active thermal regulation (PWM) |
| Beam Pattern | OEM-style, no-glare precision filament design |
| Housing Compatibility | Classic reflector housings, sealed-beam buckets |
| Warranty | 3-Year |
What's in the Box
- (1) Pair of Vintage Series LED headlight bulbs in your selected fitment
Frequently Asked Questions
Which bulb fitments are available?
The Vintage Series is offered in H4, H10, 9003, and 9004. Check your owner's manual or a bulb fitment guide to confirm your size before ordering.
Why is the color temperature warm instead of bright white?
The 3000K-3500K warm white is intentional. It closely matches the look of original sealed-beam and halogen bulbs so your classic keeps its period-correct appearance day or night.
Do these need cooling fans?
No. They use fanless active thermal management with PWM current regulation, so they run quiet and fit into tight sealed-beam housings where fan-equipped bulbs will not.
Will they fit older sealed-beam housings?
Yes. The true drop-in shape and lack of bulky heat sinks are designed specifically for classic reflector housings and older headlamp buckets, with no trimming or custom brackets.
What warranty is included?
These bulbs carry a 3-year warranty. An install guide (PDF) is available.
