FOX Billet Upper Control Arms, Orange, fits Ford F-150

SKU: 803-35-015

FOX Billet Upper Control Arms, Orange for Ford F-150 (2021-2026)

By FOX

$1,679.95

180-Day ReturnsOn uninstalled, unused parts Real humans who wheel(920) 249-7744 Financing available

For qualified buyers at checkout Secure checkoutEncrypted payment

Confirmed fit: 2021–2026 Ford F-150

Verified to fit the 2021–2026 Ford F-150.

Warranty Information

FOX warranty summary coming soon.

More details

FOX Billet Upper Control Arms, Orange for Ford F-150 (2021-2026)

Billet aluminum upper control arms for the 2021-2026 Ford F-150 (not the Raptor), finished in orange. Lifting a truck pushes the factory alignment out of range, and these arms bring caster back while giving you adjustment. The kit includes hardware that works with the factory ride height sensor.

Why it works

Alignment correctionAdjustable arms bring caster and camber back into range after you lift the front end.

More droop travelThe geometry is optimized to allow additional articulation off-road.

Billet constructionThe arms are CNC machined in the USA from T6061 aluminum with an anodized finish.

Sensor-friendlyIncluded hardware accommodates the factory ride height sensor.

Specifications

Spec	Detail
Fitment	Ford F-150 2021-2026, excludes Raptor
Position	Front upper
Material	T6061 billet aluminum
Finish	Orange, Type II anodized
Joints	1.25 in. uniballs, 3/4 in. chromoly heim joints
Adjustment	Caster and camber

Before you order

Excludes the Raptor submodel. Includes hardware to keep the OEM ride height sensor working. Listed as a bolt-on with no chassis modification. FOX install instructions: download the PDF. Not sure it fits your build? Call real humans at (920) 249-7744 with your year, trim and setup and we will confirm it.

Frequently asked questions

Do these fit the Raptor?

No. The Raptor submodel is excluded.

Will it work with the ride height sensor?

Yes. The kit includes hardware to accommodate the OEM sensor.

Are they adjustable?

Yes. The heim joints allow adjustment of caster and camber.

Where are they made?

FOX states the arms are CNC machined in the USA.

What is the warranty?

Coverage depends on the product line; see our FOX warranty page for the term that applies.
