ORACLE Pre-Wired Power Symbol Flush Mount LED Switch
ORACLE Pre-Wired Power Symbol Flush Mount LED Switches take your interior to the next level with a premium, sophisticated look. Each switch features the iconic ORACLE power symbol that glows in your chosen LED color, a heavy-duty brass assembly, and a nickel-plated metal housing with a definitive tactile click. Available in On/Off (latching) and Momentary (spring-return) styles across seven LED colors.
Key Features
- Illuminated ORACLE power symbol glows in your chosen LED color when activated
- Heavy-duty brass assembly for long-term durability
- Corrosion-resistant nickel-plated metal housing
- Definitive tactile click provides clear engagement feedback
- On/Off (latching) style for lighting and accessories; Momentary (spring-return) style for horns and triggers
- Seven LED colors: White, Blue, Red, Green, Amber, Yellow, and UV/Purple
- Fits any standard 16mm flush-mount panel or dash hole
- Pre-wired connector — no soldering required; CE compliant
Fitment & Compatibility
Universal 12V fitment. Installs into any standard 16mm flush-mount panel or dash hole. Note: the Momentary style is not available in White or Yellow.
Specifications
| Specification | Detail |
|---|---|
| Switch Styles | On/Off (Latching) & Momentary |
| LED Colors | White, Blue, Red, Green, Amber, Yellow, UV/Purple |
| Operating Voltage | 12V |
| Maximum Amperage | 5A @ 12V DC |
| Mounting Hole | 16mm |
| Mount Type | Flush mount |
| Housing Material | Brass assembly / nickel-plated finish |
| Wiring | Pre-wired connector included |
| Compliance | CE compliant |
| Warranty | 1 Year |
Part Numbers
| ORACLE Part # | Style | LED Color |
|---|---|---|
| 2009-001 | On/Off | White |
| 2009-002 | On/Off | Blue |
| 2009-003 | On/Off | Red |
| 2009-004 | On/Off | Green |
| 2009-005 | On/Off | Amber |
| 2009-006 | On/Off | Yellow |
| 2009-007 | On/Off | UV/Purple |
| 2058-002 | Momentary | Blue |
| 2058-003 | Momentary | Red |
| 2058-004 | Momentary | Green |
| 2058-005 | Momentary | Amber |
| 2058-007 | Momentary | UV/Purple |
What's in the Box
- (1) ORACLE Power Symbol Flush Mount LED Switch in your chosen style and color
- (1) Pre-wired connector
Frequently Asked Questions
What is the difference between On/Off and Momentary?
The On/Off (latching) style stays in position when pressed — ideal for lighting and accessories. The Momentary (spring-return) style is active only while held — ideal for horns, triggers, and momentary functions.
What colors are available?
Seven LED colors: White, Blue, Red, Green, Amber, Yellow, and UV/Purple. Note the Momentary style is not offered in White or Yellow.
How is it installed?
Drill or locate a 16mm mounting hole in your panel or dash, insert and secure the switch, and connect the pre-wired connector to your 12V circuit. No soldering is required, and install takes about 15 minutes.
What are the electrical ratings?
The switch operates at 12V with a maximum of 5A at 12V DC, and it is CE compliant with a 1-year warranty.
