SKU: D56017907050
Fuel Vapor Wheel - 17"
By Fuel
$320.00
Size
Bolt Pattern
180-Day ReturnsOn uninstalled, unused parts
Real humans who wheel(920) 249-7744
PayPal Credit acceptedFinancing option at checkout
Secure checkoutEncrypted payment
The Fuel Vapor makes a bold statement with its thick, concave spoke design and rugged attitude, built to handle serious off-road challenges. This one-piece cast wheel combines strength and style, with load ratings up to 3,700 lbs to back up its looks. Available in 5-lug, 6-lug, and 8-lug configurations, the Vapor is a solid choice for everything from Jeep Wranglers and Toyota Tacomas to Ford F-150s and heavy-duty trucks like the Silverado 3500 and RAM 3500.
Specifications
| Part # | Finish | Size / Offset | Bolt Pattern | Backspace | Center Bore | Load Rating | Weight |
|---|---|---|---|---|---|---|---|
| D56017907045 | Matte Black | 17x9 -12mm | 5x139.7/5x150 | 4.53" | 110.10mm | 2500 lbs | 36.99 lbs |
| D56017908245 | Matte Black | 17x9 -12mm | 8x165.1 | 4.53" | 125.10mm | 3500 lbs | 37.00 lbs |
| D56017909845 | Matte Black | 17x9 -12mm | 6x135/6x139.7 | 4.53" | 106.10mm | 2500 lbs | 37.00 lbs |
| D56017902645 | Matte Black | 17x9 -12mm | 5x114.3/5x127 | 4.53" | 78.10mm | 2500 lbs | 37.00 lbs |
| D56917902645A | Matte Black Double Dark Tint | 17x9 -12mm | 5x114.3/5x127 | 4.53" | 78.10mm | 2500 lbs | 37.00 lbs |
| D85117909845A | Matte Black Gray Tint | 17x9 -12mm | 6x135/6x139.7 | 4.53" | 106.10mm | 2500 lbs | 37.00 lbs |
| D56017907050 | Matte Black | 17x9 1mm | 5x139.7/5x150 | 5.04" | 110.10mm | 2500 lbs | 37.00 lbs |
| D56017901850 | Matte Black | 17x9 1mm | 8x180 | 5.04" | 124.20mm | 3500 lbs | 37.00 lbs |
| D56017902650 | Matte Black | 17x9 1mm | 5x114.3/5x127 | 5.04" | 78.10mm | 2500 lbs | 37.00 lbs |
| D56017908250 | Matte Black | 17x9 1mm | 8x165.1 | 5.04" | 125.10mm | 3500 lbs | 37.00 lbs |
| D56017909850 | Matte Black | 17x9 1mm | 6x135/6x139.7 | 5.04" | 106.10mm | 2500 lbs | 37.00 lbs |
| D56917902650A | Matte Black Double Dark Tint | 17x9 1mm | 5x114.3/5x127 | 5.04" | 78.10mm | 2500 lbs | 37.00 lbs |
| D56917908250A | Matte Black Double Dark Tint | 17x9 1mm | 8x165.1 | 5.04" | 125.10mm | 3500 lbs | 37.00 lbs |
| D85117902650A | Matte Black Gray Tint | 17x9 1mm | 5x114.3/5x127 | 5.04" | 78.10mm | 2500 lbs | 37.00 lbs |
| D85117908250A | Matte Black Gray Tint | 17x9 1mm | 8x165.1 | 5.04" | 125.10mm | 3500 lbs | 37.00 lbs |
| D85117909850A | Matte Black Gray Tint | 17x9 1mm | 6x135/6x139.7 | 5.04" | 106.10mm | 2500 lbs | 37.00 lbs |
| D56017908457 | Matte Black | 17x9 20mm | 6x139.7 | 5.79" | 106.10mm | 2100 lbs | 34.00 lbs |
| D56917908457 | Matte Black Double Dark Tint | 17x9 20mm | 6x139.7 | 5.79" | 106.10mm | 2100 lbs | 34.00 lbs |
| D56017009847 | Matte Black | 17x10 -18mm | 6x135/6x139.7 | 4.79" | 106.10mm | 2500 lbs | 38.00 lbs |
| D56017007047 | Matte Black | 17x10 -18mm | 5x139.7/5x150 | 4.79" | 110.10mm | 2500 lbs | 38.00 lbs |
