Fuel Crush Wheel
For qualified buyers at checkout
Secure checkoutEncrypted payment
Warranty Information
Vendor warranty summary
Fuel Off-Road Warranty
At a glance: Lifetime structural warranty; finish coverage 90 days to 2 years depending on finish
This is Fuel Off-Road's warranty, not an NVMOS policy. We've summarized it in plain English to save you a search. The manufacturer's official terms always govern and can change without notice. Last reviewed on nvmos.com: October 4, 2026.
Coverage by product
| Product or component | Coverage |
|---|---|
| Wheel structure | Lifetime (original retail purchaser) |
| PVD finishes (peeling/lifting) | 2 years |
| Chrome aluminum finish (peeling/lifting; pitting excluded) | 1 year |
| Painted aluminum finish (peeling/lifting) | 1 year |
| Steel wheel paint or plating | 90 days (surface rust/corrosion excluded) |
| Uncoated polished aluminum | Not covered |
- Original purchaser only — coverage does not transfer if you sell it.
- Keep your NVMOS order confirmation — proof of purchase is required.
What's covered
- Structural failure under normal, intended use for as long as the original buyer owns the wheels
- Finish peeling or lifting within the finish's coverage period
- Approved wheels are repaired or replaced
What's not covered
- Wheels not installed per Fuel's installation guidelines
- Damage from poor maintenance or harsh cleaning chemicals
- Structural damage from accidents or road hazards
- Racing or improper vehicle use
- Use of unapproved accessories or adapters
- Removal, mounting, installation and shipping costs
How to make a Fuel Off-Road warranty claim
- Return the wheel with the original sales receipt to the retailer you bought it from
- The wheel is inspected; approved claims are repaired or replaced
- You pay removal, shipping and reinstall costs; rejected wheels are sent back at your expense
Fuel Off-Road contact: Phone: 877-883-0852 · Claim page / support
Bought it from NVMOS? Start with us.
Have your order number and a few photos of the issue ready, then call real humans at (920) 249-7744 or send us a message. We'll tell you whether the claim goes through us or straight to Fuel Off-Road, and help it along either way.
Shop Fuel Off-Road at NVMOS
See all Fuel Off-Road products, lead times and FAQs →
Disclaimer: The information on this page describes Fuel Off-Road's own warranty policy. It is not a warranty offered by NVMOS (No Visible Means of Support LLC). Manufacturers update their terms at any time; we review these pages periodically, but the manufacturer's current official policy is the one that applies to your claim. Source: Fuel Off-Road official warranty information. Last updated on nvmos.com: October 4, 2026. See our return policy for NVMOS's own terms.
About the brand
Fuel Off-Road is the aggressive-styled wheel brand MHT Luxury Alloys launched in 2008, with sizes and fitments for nearly every truck and SUV. NVMOS carries Fuel off-road wheels from 15 to 24 inches, plus dually and beadlock wheels. For trucks that are lifted, about to be lifted, or doing heavy work.
Founded: 2008 · Lead time: In-stock items ship in 24–48 hours
Shop all 293 Fuel Off-RoadWarrantyAll brands
Warranty terms are set by Fuel Off-Road, not NVMOS, and can change. Bought from us? Call (920) 249-7744 and we'll handle the claim with the brand.
Fuel Crush Wheel
The Fuel Crush has a bold eight-spoke split design, a deep concave face and a gloss machined finish. It is built from durable cast aluminum for street duty or off-road. Browse off-road wheels.
It comes in 5, 6 and 8-lug patterns from 17 to 22 inch, for Wranglers, Tacomas, F-150s, Silverado 1500s and RAM 1500s, plus F-250, F-350, Silverado and RAM 2500 and 3500. Offsets run from -44mm to +20mm. See non-beadlock wheels.
Finishes: Gloss Machined Double Dark Tint. Sizes (diameter x width, offset): 20x9 1mm, 18x9 -12mm, 17x9 -12mm, 17x9 1mm, 20x10 -18mm, 18x9 19mm, 18x9 1mm, 20x9 20mm, 20x9 19mm, 18x9 20mm, 20x10 -19mm. Bolt patterns: 8x165.1, 6x135/6x139.7, 5x114.3/5x127, 8x170, 5x139.7/5x150, 6x120/6x139.7, 8x180.
| Part # | Finish | Size / Offset | Bolt Pattern | Backspace | Center Bore | Load Rating | Weight |
|---|---|---|---|---|---|---|---|
| D56117902645 | Gloss Machined Double Dark Tint | 17x9 -12mm | 5x114.3/5x127 | 4.53" | 78.10mm | 2500 lbs | 35.00 lbs |
| D56117907045 | Gloss Machined Double Dark Tint | 17x9 -12mm | 5x139.7/5x150 | 4.53" | 110.10mm | 2500 lbs | 35.00 lbs |
| D56117902650 | Gloss Machined Double Dark Tint | 17x9 1mm | 5x114.3/5x127 | 5.04" | 78.10mm | 2500 lbs | 35.00 lbs |
| D56117909850 | Gloss Machined Double Dark Tint | 17x9 1mm | 6x135/6x139.7 | 5.04" | 106.10mm | 2500 lbs | 35.00 lbs |
| D56117907050 | Gloss Machined Double Dark Tint | 17x9 1mm | 5x139.7/5x150 | 5.04" | 110.10mm | 2500 lbs | 35.00 lbs |
| D56118909845 | Gloss Machined Double Dark Tint | 18x9 -12mm | 6x135/6x139.7 | 4.53" | 106.10mm | 2500 lbs | 36.00 lbs |
| D56118902645 | Gloss Machined Double Dark Tint | 18x9 -12mm | 5x114.3/5x127 | 4.53" | 78.10mm | 2500 lbs | 36.00 lbs |
| D56118909850 | Gloss Machined Double Dark Tint | 18x9 1mm | 6x135/6x139.7 | 5.04" | 106.10mm | 2500 lbs | 36.00 lbs |
| D56118908250 | Gloss Machined Double Dark Tint | 18x9 1mm | 8x165.1 | 5.04" | 125.10mm | 3700 lbs | 36.00 lbs |
| D56118901850 | Gloss Machined Double Dark Tint | 18x9 1mm | 8x180 | 5.04" | 124.20mm | 3700 lbs | 36.00 lbs |
| D56118906957 | Gloss Machined Double Dark Tint | 18x9 19mm | 6x120/6x139.7 | 5.75" | 78.10mm | 2500 lbs | 32.00 lbs |
| D56118908257 | Gloss Machined Double Dark Tint | 18x9 20mm | 8x165.1 | 5.79" | 125.10mm | 3700 lbs | 35.00 lbs |
| D56118907057 | Gloss Machined Double Dark Tint | 18x9 20mm | 5x139.7/5x150 | 5.79" | 110.10mm | 2500 lbs | 35.00 lbs |
| D56120908250 | Gloss Machined Double Dark Tint | 20x9 1mm | 8x165.1 | 5.04" | 125.10mm | 3700 lbs | 42.00 lbs |
| D56120901750 | Gloss Machined Double Dark Tint | 20x9 1mm | 8x170 | 5.04" | 125.10mm | 3700 lbs | 42.00 lbs |
| D56120909850 | Gloss Machined Double Dark Tint | 20x9 1mm | 6x135/6x139.7 | 5.04" | 106.10mm | 2500 lbs | 42.00 lbs |
| D56120909856 | Gloss Machined Double Dark Tint | 20x9 19mm | 6x135/6x139.7 | 5.75" | 106.10mm | 2500 lbs | 42.00 lbs |
| D56120907057 | Gloss Machined Double Dark Tint | 20x9 20mm | 5x139.7/5x150 | 5.79" | 110.10mm | 2500 lbs | 42.00 lbs |
| D56120901857 | Gloss Machined Double Dark Tint | 20x9 20mm | 8x180 | 5.79" | 124.20mm | 3700 lbs | 42.00 lbs |
| D56120002647 | Gloss Machined Double Dark Tint | 20x10 -18mm | 5x114.3/5x127 | 4.79" | 78.10mm | 2500 lbs | 42.00 lbs |
| D56120001847 | Gloss Machined Double Dark Tint | 20x10 -18mm | 8x180 | 4.79" | 124.20mm | 3700 lbs | 42.00 lbs |
| D56120001747 | Gloss Machined Double Dark Tint | 20x10 -18mm | 8x170 | 4.79" | 125.10mm | 3700 lbs | 42.00 lbs |
| D56120008247 | Gloss Machined Double Dark Tint | 20x10 -18mm | 8x165.1 | 4.79" | 125.10mm | 3700 lbs | 42.00 lbs |
| D56120009846 | Gloss Machined Double Dark Tint | 20x10 -19mm | 6x135/6x139.7 | 4.75" | 106.10mm | 2500 lbs | 42.00 lbs |
Complete your build
The pieces owners run with this one — matched to your build and to each other. Do the whole truck in one order instead of three.
$286.00
$3,149.95
$613.00
$516.95
Specifications
Fuel Crush Wheel FAQs
What is it made of?
Durable cast aluminum.
What finish?
Gloss Machined Double Dark Tint.
What sizes?
17 to 22 inch per Fuel; this listing shows 17, 18 and 20 inch sizes.
What trucks?
Wranglers, Tacomas, F-150, Silverado 1500, RAM 1500 and heavy-duty trucks.
