Carbon 4.5k 4500lb ATV/Trailer Winch

Carbon 4.5k 4500lb ATV/Trailer Winch Off-Road Recovery Winch

Built for heavier side-by-sides and utility vehicles, the ATV 4.5K offers 4,500lb capacity and a compact, rugged build.

Designed for ATVs, UTVs, side-by-sides, car trailers and equipment transport; this winch is ideal for mounting in the back of a van to help load heavy equipment, and has even been used to load tinnies and open cattle gates on livestock truck trailers.

Key Features

• Built for heavier side-by-sides and utility vehicles, the ATV 4.5K offers 4,500lb capacity and a compact, rugged build
• 4,500lb (2,041kg) Rated Pull – Extra capacity for demanding ATV/UTV use 1.9HP Motor – Compact with reliable pulling power 176:1 Gear Ratio – Strong, controlled operation 43ft (13m) Synthetic Rope – Lightweight and durable Mounting Bolt Pattern – 6.57in x 2.99in (167mm x 76mm) Drum Dimensions – 1.26in x 2.87in (32mm x 73mm) Winch Dimensions – 14.92in x 4.72in x 4.53in (379mm x 120mm x 115mm) IP66 Rated winch and solenoid (excludes remote control and switch) Wired + Wireless Remotes – Flexible control options 12V DC PERFORMANCE SPECS (first layer of drum) Line Pull Lbs.(Kgs.) Line Speed FT./min(M/min.) Motor Current Pull by layer layer/Lbs(Kgs.) 0 20.4(6.2) 31 Amps 1/4500(2040) 1000 14.2(4.3) 65Amps 2/3750(1700) 2000 10.9(3.3) 96Amps 3/3510(1595) 3000 7.7(2.4) 125Amps 4/3300(1500) 4500 4.9(1.5) 175.Amps
• Designed for ATVs, UTVs, side-by-sides, car trailers and equipment transport; this winch is ideal for mounting in the back of a van to help load heavy equipment, and has even been used to load tinnies and open cattle gates on livestock truck trailers

Why Choose This Product

Choose Carbon 4.5k 4500lb ATV/Trailer Winch when you need proven pulling power, dependable recovery performance, and hardware built for off-road, overland, and heavy-duty use.

Perfect For

Trucks, Jeeps, SUVs, overland rigs, trailers, farm vehicles, work vehicles, and off-road recovery setups.

Product Details

• Built for heavier side-by-sides and utility vehicles, the ATV 4.5K offers 4,500lb capacity and a compact, rugged build
• 4,500lb (2,041kg) Rated Pull – Extra capacity for demanding ATV/UTV use 1.9HP Motor – Compact with reliable pulling power 176:1 Gear Ratio – Strong, controlled operation 43ft (13m) Synthetic Rope – Lightweight and durable Mounting Bolt Pattern – 6.57in x 2.99in (167mm x 76mm) Drum Dimensions – 1.26in x 2.87in (32mm x 73mm) Winch Dimensions – 14.92in x 4.72in x 4.53in (379mm x 120mm x 115mm) IP66 Rated winch and solenoid (excludes remote control and switch) Wired + Wireless Remotes – Flexible control options 12V DC PERFORMANCE SPECS (first layer of drum) Line Pull Lbs.(Kgs.) Line Speed FT./min(M/min.) Motor Current Pull by layer layer/Lbs(Kgs.) 0 20.4(6.2) 31 Amps 1/4500(2040) 1000 14.2(4.3) 65Amps 2/3750(1700) 2000 10.9(3.3) 96Amps 3/3510(1595) 3000 7.7(2.4) 125Amps 4/3300(1500) 4500 4.9(1.5) 175.Amps
• Designed for ATVs, UTVs, side-by-sides, car trailers and equipment transport; this winch is ideal for mounting in the back of a van to help load heavy equipment, and has even been used to load tinnies and open cattle gates on livestock truck trailers
