Carbon Offroad - RS9-S 9000lb Short Drum Winch

Carbon Offroad - RS9-S 9000lb Short Drum Winch Off-Road Recovery Winch

The Carbon Offroad Scout Pro RS9-S (Short Drum): Pure Race Power Maximum Muscle.

When you’re piloting a race buggy, UTV, or specialized ATV, every millimeter and every gram counts.

Key Features

• The Carbon Offroad Scout Pro RS9-S (Short Drum): Pure Race Power Maximum Muscle
• The Scout Pro RS9-S is the short-drum evolution of our high-speed series—designed specifically for tight spaces where you refuse to compromise on recovery speed or pulling power
• This is the same 8.0HP powerhouse found in our full-size rigs, shortened down for elite racing applications
• Built on our ultra-lightweight chassis, it comes standard with 24m (80ft) of 8mm Spectra™ Fiber synthetic rope
• Feature Specification (Metric / Imperial) Rated Line Pull 4,080kg (9,000lb) Motor 8.0HP 12V Series-Wound Gear Ratio 80:1 Heavy-Duty Performance Gearing Rope Dimensions 8mm x 24m (5/16" x 80ft) Rope Material Spectra™ Fiber Synthetic UHMWPE Water/Dust Sealing IP68 Rated Winch Dimensions (L x W x H) 385mm x 115mm x 120mm (15.16" x 4.53" x 4.7") Drum Diameter x Length 63mm x 122mm (2.5" x 4.8") Mounting Bolt Pattern 164mm x 114.3mm (6.46" x 4.5") Included Hardware MegaPro Hook, Fairlead, Wiring Accessory Kit Winch Weight 22kg (48.4lb) Line Pull (lbs / kgs) Line Speed (ft/min / m/min) Motor Current (Amps) 0 79.4 ft (24.2 m) 55 A 4000 lbs (1816 kg) 18.4 ft (5.6 m) 180 A 7000 lbs (3180 kg) 13.8 ft (4.2 m) 310 A 9000 lbs (4090 kg) 8.5 ft (2.6 m) 440 A Layer Rated Line Pull (lbs / kgs) 1 9000 lbs (4090 kg) 2 7760 lbs (3524 kg) 3 6690 lbs (3040 kg) 4 5760 lbs (2615 kg) Builder & Racer Note The RS9-S features a shortened drum and chassis to fit narrow mounting locations common in race buggies and UTVs

Why Choose This Product

Choose Carbon Offroad - RS9-S 9000lb Short Drum Winch when you need proven pulling power, dependable recovery performance, and hardware built for off-road, overland, and heavy-duty use.

Perfect For

Trucks, Jeeps, SUVs, overland rigs, trailers, farm vehicles, work vehicles, and off-road recovery setups.

Product Details

• The Carbon Offroad Scout Pro RS9-S (Short Drum): Pure Race Power Maximum Muscle
• The Scout Pro RS9-S is the short-drum evolution of our high-speed series—designed specifically for tight spaces where you refuse to compromise on recovery speed or pulling power
• This is the same 8.0HP powerhouse found in our full-size rigs, shortened down for elite racing applications
• Built on our ultra-lightweight chassis, it comes standard with 24m (80ft) of 8mm Spectra™ Fiber synthetic rope
• Feature Specification (Metric / Imperial) Rated Line Pull 4,080kg (9,000lb) Motor 8.0HP 12V Series-Wound Gear Ratio 80:1 Heavy-Duty Performance Gearing Rope Dimensions 8mm x 24m (5/16" x 80ft) Rope Material Spectra™ Fiber Synthetic UHMWPE Water/Dust Sealing IP68 Rated Winch Dimensions (L x W x H) 385mm x 115mm x 120mm (15.16" x 4.53" x 4.7") Drum Diameter x Length 63mm x 122mm (2.5" x 4.8") Mounting Bolt Pattern 164mm x 114.3mm (6.46" x 4.5") Included Hardware MegaPro Hook, Fairlead, Wiring Accessory Kit Winch Weight 22kg (48.4lb) Line Pull (lbs / kgs) Line Speed (ft/min / m/min) Motor Current (Amps) 0 79.4 ft (24.2 m) 55 A 4000 lbs (1816 kg) 18.4 ft (5.6 m) 180 A 7000 lbs (3180 kg) 13.8 ft (4.2 m) 310 A 9000 lbs (4090 kg) 8.5 ft (2.6 m) 440 A Layer Rated Line Pull (lbs / kgs) 1 9000 lbs (4090 kg) 2 7760 lbs (3524 kg) 3 6690 lbs (3040 kg) 4 5760 lbs (2615 kg) Builder & Racer Note The RS9-S features a shortened drum and chassis to fit narrow mounting locations common in race buggies and UTVs
• Despite its compact 385mm (1 5.16 inch ) length, it retains the full-sized 8.0HP motor
